Guidance for compliance with survey and certification of
marine diesel engines, as described in chapter
2 of this Code, are shown in the flow charts on the next three
pages as follows:
-
Figure 1. Flow chart, step
I - Pre-certification survey at the manufacturer's shop
-
Figure 2. Flow chart, step
II - Initial survey on board the ship
-
Figure 3. Flow chart, step
III - Periodical survey on board a ship
Figure 1 Flow chart, step I - Pre-certification Survey at the manufacturer's
shop
Figure 2 Flow chart, step II - Initial Survey on board the ship
Figure 3 Flow chart, step III - Periodical Survey on board a ship
