7 Rescue Boats and Fast
Rescue Boats
7.1 Rigid rescue boats
7.1.1 Rigid rescue boats should be subjected to
the tests prescribed in 6.2 to 6.12 (except 6.3, 6.4.2, 6.5, 6.6.2,
6.7.1, 6.9.6, 6.9.7, 6.10.1) and 7.2.4.2.
Towing test
7.1.2 The maximum towing force of the rescue boat
should be determined. This information should be used to determine
the largest fully loaded liferaft the rescue boat can tow at two knots.
The fitting designated for towing other craft should be secured to
a stationary object by a tow rope. The engine should be operated ahead
at full speed for a period of at least 2 min, and the towing force
measured and recorded. There should be no damage to the towing fitting
or its supporting structure. The maximum towing force of the rescue
boat should be recorded on the type approval certificate.
Rigid rescue boat seating test
7.1.3 The rigid rescue boat should be fitted with
its engine and all its equipment. The number of persons for which
the rescue boat is to be approved, having an average mass of at least
82.5 kg and all wearing lifejackets and immersion suits and any other
essential equipment required should then board; one person should
lie down on a stretcher of similar dimensions to those shown in figure 4 and the others should be properly
seated in the rescue boat. The rigid rescue boat should then be manoeuvred
and all equipment on board tested to demonstrate that it can be operated
without difficulty or interference with the occupants.
Figure 4 Stretcher dimensions (mm)
Overload test
7.1.4 The boat should be loaded with properly
distributed load of four times the weights to represent the equipment
and full complement of persons, each weighing 82.5 kg, for which it
is to be approved and suspended for five minutes from its bridle or
hooks. The weights should be distributed in proportion to the loading
of the boat in its service condition, but the weights used to represent
the persons need not be placed 300 mm above the seat pan. The boat
and bridle or hooks and fastening device should be examined after
the test has been conducted and should not show any signs of damage.
Testing by filling the boat with water should not be accepted. This
method of loading does not give the proper distribution of weight.
Machinery may be removed in order to avoid damage, in which case weights
should be added to the boat to compensate for the removal of such
machinery.
Operation tests
7.1.5 Operation of engine and fuel consumption
test
The boat should be loaded with weights equal to the mass of
its equipment and the number of persons for which the boat is to be
approved. The engine should be started and the boat manoeuvred for
a period of at least 4 h to demonstrate satisfactory operation.
The boat should be run at a speed of not less than 6 knots for
a period which is sufficient to ascertain the fuel consumption and
to establish that the fuel tank has the required capacity.
7.1.6 Speed and manoeuvring trials should be carried
out with engines of various powers to assess the rescue boat's performance
(if a rigid rescue boat is equipped with outboard motor).
Righting test
7.1.7 It should be demonstrated that both with
and without engine and fuel or an equivalent mass in place of the
engine and fuel tank, the rescue boat is capable of being righted
by not more than two persons if it is inverted on the water. In the
case of fast rescue boats which are not self-righting, the engine
should be running in neutral position and, after stopping automatically
or by the helmsman's emergency release switch when inverted, it should
be easily restarted and run for 30 min after the rescue boat has returned
to the upright position. For rescue boats with inboard engines, the
test without engine and fuel is not applicable.
Manoeuvrability test
7.1.8 It should be demonstrated that the rigid
rescue boat can be propelled and manoeuvred by its oars or paddles
in calm water conditions at a speed of at least 0.5 knots over a distance
of at least 25 m, when laden with the number of persons, all wearing
lifejackets and immersion suits, for which it is to be approved.
Detailed inspection
7.1.9 The rigid rescue boat, complete in all respects
should be subjected to detailed inspection to ensure that all the
requirements are fulfilled.
7.2 Inflated rescue boats
Drop tests
7.2.2 The inflated rescue boat complete with all
its equipment and with a mass equivalent to its engine and fuel in
the position of its engine and fuel tank should be dropped three times
from a height of at least 3 m on to water. The drops should be from
the 45° bow-down, level-trim and 45° stern-down attitudes.
7.2.3 On completion of these drop tests the rescue
boat and its equipment should be carefully examined and show no signs
of damage which would affect their efficient functioning.
Loading tests
7.2.4 The freeboard of the inflated rescue boat
should be taken in the various loading conditions as follows:
-
.1 rescue boat with all its equipment;
-
.2 rescue boat with all its equipment, engine
and fuel, or an equivalent mass positioned to represent engine and
fuel;
-
.3 rescue boat with all its equipment and the
number of persons for which it is to be approved having an average
mass of 82.5 kg so arranged that a uniform freeboard is achieved at
the side buoyancy tubes; and
-
.4 rescue boat with the number of persons for
which it is to be approved and all its equipment, engine and fuel
or an equivalent mass to represent engine and fuel and the rescue
boat being retrimmed as necessary.
7.2.5 With the rescue boat in any of the conditions
prescribed in 7.2.4, the minimum freeboard should be not less than
300 mm at the buoyancy tubes and not less than 250 mm from the lowest
part of the transom.
Stability test
7.2.6 The following tests should be carried out
with engine and fuel or an equivalent mass in place of the engine
and fuel tanks:
-
.1 the number of persons for which the inflated
rescue boat is to be approved should be crowded to one side with half
this complement seated on the buoyancy tube, and then to one end.
In each case the freeboard should be recorded. Under these conditions
the freeboard should be everywhere positive; and
-
.2 the stability of the rescue boat during boarding
should be ascertained by two persons in the rescue boat demonstrating
that they can readily assist from the water a third person who is
required to feign unconsciousness. The third person should have his
back towards the side of the rescue boat so that he cannot assist
the rescuers. All persons should wear approved lifejackets.
7.2.7 These stability tests may be carried out
with the rescue boat floating in still water.
Damage test
7.2.8 The following tests should be carried out
with the inflated rescue boat loaded with the number of persons for
which it is to be approved both with and without engine and fuel or
an equivalent mass in the position of the engine and fuel tank:
-
.1 with forward buoyancy compartment deflated;
-
.2 with the entire buoyancy on one side of the
rescue boat deflated; and
-
.3 with the entire buoyancy on one side and the
bow compartment deflated.
7.2.9 In each of the conditions prescribed by
7.2.8 , the full number of persons for which the rescue boat is to
be approved should be supported within the rescue boat.
Simulated heavy weather test
7.2.10 To simulate use in heavy weather the inflated
rescue boat should be fitted with a larger powered engine than is
intended to be fitted and driven hard in a wind of force 4 or 5 or
equivalent rough water for at least 30 min. As a result of this test
the rescue boat should not show undue flexing or permanent strain
nor have lost more than minimal pressure.
Swamp test
7.2.11 It should be demonstrated that the rescue
boat, when fully swamped, is capable of supporting its full equipment,
the number of persons, each weighing 82.5 kg, for which it is to be
approved and a mass equivalent to its engine and fully filled fuel
tank. It should also be demonstrated that the rescue boat does not
seriously deform in this condition.
Overload tests
7.2.12 The inflated rescue boat should be loaded
with four times the mass of the full complement of persons and equipment
for which it is to be approved and suspended for five minutes from
its bridle at an ambient temperature of +20 ± 3°C with
all relief valves inoperative. The rescue boat and bridle should be
examined after the test is conducted and should not show any signs
of damage.
7.2.13 The inflated rescue boat after 6 h conditioning
at a temperature of -30°C should be loaded with 1.1 times the
mass of the full complement of persons and equipment for which it
is to be approved and suspended for five minutes from its bridle with
all relief valves operative. The rescue boat and bridle should be
examined after the test is conducted and should not show any signs
of damage.
Material tests
7.2.14 The material used in the construction of
inflated rescue boats should be tested for the following characteristics
and comply with the requirements of an international standard acceptable
to the Organizationfootnote:
Mooring out test
7.2.15 The inflated rescue boat should be subjected
to the tests indicated in 5.5
Detailed inspection
7.2.16 The inflated rescue boat complete in all
respects should be fully inflated in the manufacturer's works and
subjected to detailed inspection to ensure that all the requirements
are fulfilled.
7.3 Rigid/inflated rescue
boats
7.3.1 Rigid/inflated rescue boats should be subjected
to the tests prescribed in 6.2 (for
hull), 7.2.14 (for inflated
part), 6.4.1,, 6.6.1, 6.7.2,
6.9.1 to 6.9.5,
6.10 (except 6.10.1) to 6.12,
7.1.2 to 7.1.8,
7.2.2 to 7.2.11,
7.2.15 and 7.2.16
7.3.2 The tests prescribed in 7.2.8, 7.2.9 and 7.2.15 do not apply
to rigid/inflated fast rescue boats if the boat has its waterline
below the lower side of the inflated tube.
7.4 Rigid fast rescue
boats
7.4.1 Rigid fast rescue boats should be subjected
to the tests prescribed in 6.2 to 6.12 (except 6.3, 6.4.2, 6.5, 6.6.2,
6.7.1, 6.9.6, 6.9.7, 6.10.1), 6.14 (if
a rigid fast rescue boat is self-righting), 7.1.2 to 7.1.4, 7.1.6, 7.1.7 (if
a rigid fast rescue boat is not self-righting), 7.1.8, 7.1.9 and 7.2.4.2. In the case of open fast
rescue boats, the self-righting test should only be done in the light
condition, and 6.14.1.1, 6.14.3,
6.14.4, and 6.14.5 are not applicable. With regard to 6.14.2, a boat fitted with a helmsman's
emergency release switch should be considered to be arranged to stop
automatically when inverted.
7.4.2
Operation tests
Operation of engine and fuel consumption test
-
7.4.2.1 The boat should be loaded with weights
equal to the mass of its equipment and the number of persons for which
the boat is to be approved. The engine should be started and the boat
manoeuvred for a period of at least 4 h to demonstrate satisfactory
operation.
-
7.4.2.2 The boat should be run at a speed of not
less than 8 knots with a full complement of persons and equipment
and 20 knots with a crew of 3 persons for a period which is sufficient
to ascertain the fuel consumption and to establish that the fuel tank
has the required capacity.
7.5 Inflated fast rescue
boats
Inflated fast rescue boats should be subjected to the tests
prescribed in 6.4.1,
6.6.1,
6.7.2,
6.9.1 to 6.9.5,
6.10 (except 6.10.1), 6.11,
6.12,
6.14 (if inflated fast rescue boat
is self-righting), 7.1.2, 7.1.3,
7.1.6 (if inflated fast rescue boat is equipped with outboard
motor), 7.1.7 (if inflated
fast rescue boat is not self-righting), 7.1.8,
7.2.2 to 7.2.16 and 7.4.2.
7.6 Rigid/inflated fast
rescue boats
Rigid/inflated fast rescue boats should be subjected to
the tests prescribed in 6.2 (for
hull), 7.2.14 (for inflated
part), 6.4.1,
6.6.1,
6.7.2,
6.9.1 to 6.9.5,
6.10 (except 6.10.1) to 6.12,
6.1.4 (if rigid/inflated fast rescue
boat is self-righting), 7.1.2 to
7.1.4, 7.1.6 (if rigid/inflated rescue boat is equipped with
outboard motor), 7.1.7 (if
rigid/inflated fast rescue boat is not self-righting), 7.1.8,
7.2.2 to 7.2.11, 7.2.15, 7.2.16,
7.3.2 and 7.4.2.
7.7 Outboard motors for
rescue boats
7.7.1 When the rescue boats are fitted with outboard
motors, the following tests should be applied to the motor in place
of those tests specified in 6.10.
Power test
7.7.2 The motor, fitted with a suitable propeller,
should be placed in a test rig such that the propeller is completely
submerged in a water tank, simulating service conditions.
7.7.3 The motor should be run at the maximum continuous
rated speed using the maximum power obtainable for 20 min, and should
not overheat or be damaged.
Water drench test
7.7.4 The motor protective cover should be removed
and the motor thoroughly drenched with water, by hose, except for
the intake to the carburettor. The motor should be started and run
at speed for at least 5 min while it is still being drenched. The
motor should not falter or be damaged by this test.
Hot start test
7.7.5 While still in the test rig referred to
in 7.7.2, the motor should be run at idling speed in order to heat
up the cylinder block. At the maximum temperature achievable, the
motor should be stopped and immediately restarted. This test should
be carried out at least twice. The motor should not fail to restart.
Manual start test
7.7.6 The motor should be started at ambient temperature
by manual means. The means should be either a manual automatic-rewind
system or a pull cord round the top flywheel of the motor. The motor
should be started twice within 2 min of commencement of the start
procedure.
7.7.7 The motor should be run until normal operating
temperatures are reached, then it should be stopped and started manually
twice within 2 min, in accordance with 7.7.6.
Cold start test
7.7.8 The motor, together with the fuel, fuel
lines and battery, should be placed in a chamber at a temperature
of -15°C and allowed to remain until the temperature of all parts
has reached the temperature of the chamber. The temperature of the
fuel, battery and motor should be measured for this test. The motor
should be started twice, within 2 min of commencement of the start
procedure, and allowed to run long enough to demonstrate that it runs
at operating speed. It is recommended that this period should not
exceed 15 s.
7.7.9 Where, in the opinion of the Administration,
having regard to the particular voyages in which the ship carrying
the boat is constantly engaged, a lower temperature is appropriate,
that lower temperature should be substituted for -15°C in 7.7.8
for the cold start test.
Engine-out-of-water test
7.7.10 The engine should be operated for at least
5 min at idling speed under conditions simulating normal storage.
The engine should not be damaged as a result of this test.
Engine inversion test (for engines destined for fast rescue
boats only)
7.7.11 The engine and its fuel tank should be
mounted on a frame that is arranged to rotate about an axis equivalent
to the longitudinal axis of the boat at the height of the boat transom.
The propeller should be in a water basin to the height of the cavitation
plate. The engine should then be subjected to the test procedure specified
in paragraphs 6.14.7.1 through 6.14.7.13, and then dismantled for examination. With regard to 6.14.7.9, the engine should be
stopped automatically or by the helmsman's emergency release switch
when inverted. During these tests, the engine should not overheat
or fail to operate or leak more than 250 ml of oil during any one
inversion. When examined after being dismantled the engine, should
show no evidence of overheating or excessive wear.
|
